Description
Usage Capabilities:
- 90° tilting from horizontal to vertical with locking facility in vertical position.
- 360° turning with locking facility every 90°.
Condition for operating the device:
- Max. elevation - 1.200 meter above sea level.
- Operating Temperatures - 0°C to +40°C
- Can be used inside and outside, however not in area with explosive danger.
- The lifter may be used in rain and snow conditions, however there should be taken care for a dry suction area.
- The device can be used then the wind speed is up to 10m/s, or when there is a chance for wind bursts.
The guideline for the maximal dimensions of the following materials:
GLASS:
thickness Horizontal transport ( l x b ) Vertical transport ( l x b )
6 mm 2.0 x 2,0 mtr. 3,0 x 3,0 mtr.
8 mm 2.4 x 2,4 mtr. 3,3 x 3,3 mtr.
10 mm 2,8 x 2,8 mtr. 3,6 x 3,6 mtr.
15+ mm 3,0 x 3,0 mtr. 4,0 x 4,0 mtr.
SANDWICH PANELS:
thickness Horizontal transport ( length ) Vertical transport ( length )
40 mm 6 mtr. 10 mtr.
60 mm 7 mtr. 11 mtr.
80 mm 8 mtr. 12 mtr.
100+mm 10 mtr. 14 mtr.
Specification
- Length, m 0.8
- Width, m 0.4
- Height, m 0.2
- Weight, kg 55
- Model GB 500
